Nickel Alloy 200 Fittings are components crafted from Nickel 200, a high-purity nickel alloy offering outstanding corrosion resistance and electrical conductivity. These fittings are produced via a forging process and find use across numerous industries, especially in settings that demand resistance to corrosive materials and elevated temperatures. They are available in various forms like elbows, tees, couplings, and plugs, functioning to link or join piping systems. Nickel Alloy 200 Fittings provide durability, reliability, and versatility, making them well-suited for critical applications in the chemical processing, petrochemical, power generation, and aerospace industries.
| Dimension Specification | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
|---|---|
| Thread | NPT, BSPT, BSPP |
| Type | DN15-DN1200 |
| End | Threaded, Welding, JIC |
| Pressure Rating | Threaded end-2000lb/ 3000lb/ 6000lbs Pipe Fittings Socket-weld end-3000/ 6000/ 9000lbs Pipe Fittings |
| Connection | Welding |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Crosses, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows – Female-Female, Male-Female, Male-Male, Union, Nipples, Couplings, Plugs Fittings |
| Application |
|
| Element | Tensile Strength | Yield Strength (0.2%Offset) | Density | Melting Point | Elongation |
| Nickel 200 | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 8.9 g/cm3 | 1446 °C (2635 °F) | 45 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
At Sumakhsteel, we take great pride in being the largest supplier and manufacturer in the USA, delivering advanced solutions for all your piping requirements. With cutting-edge production facilities strategically situated across the USA, we maintain a large inventory of more than 25,000 tons of top-quality materials kept ready in stock.
Reach out to us for a fast quote tailored to your needs.
We provide these Nickel Alloy 200 Pipe Fittings in accordance with DIN, ISO, JIS or ANSI Standard.
Nickel Alloy 200 Pipe Fittings uses are as varied as the industries they cater to led chiefly by the aerospace, railway, construction and automotive sectors along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes Nickel Alloy 200 Fittings are, moreover, recyclable. As with other nickel alloys, Nickel 200 can be reclaimed through a range of processes including melting and refining. Recycling these fittings serves to preserve natural resources, cut down energy use, and lessen the environmental impact tied to mining and producing new materials. Furthermore, recycling supports the sustainability of industrial operations by encouraging the reuse of valuable materials, which makes it an environmentally responsible practice.
Yes, Nickel Alloy 200 Pipe Fittings can be recycled, supporting the sustainability of industrial processes by encouraging the reuse of valuable materials and lessening environmental impact.
Yes, Pipe Fittings made from Nickel Alloy 200 retain their mechanical characteristics across a broad range of temperatures, which makes them well-suited for high-temperature uses like those in the power generation and aerospace sectors.
Yes, Nickel Alloy 200 Pipe Fittings deliver outstanding resistance to corrosion and are well-suited for deployment in corrosive settings like those encountered in the chemical processing, marine, and oil and gas sectors.
