Stainless Steel JIC (Joint Industry Council) fittings are indispensable for high-pressure hydraulic systems, valued for their sturdy and leak-free connections. Constructed from durable stainless steel, these fittings resist corrosion and endure harsh environments. The 37-degree flare design guarantees secure, dependable performance across a range of applications. Perfect for demanding industries, stainless steel JIC fittings deliver outstanding longevity and efficiency in fluid power systems, boosting overall operational reliability.
| BRAND | TU-LOK |
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | BRASS |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM) L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY) S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | NATURAL FINISH, NICKEL PLATED |
| TEMPERATURE | BRASS – (-60*C TO 175*C) |
| EQUIVALENT BRANDS | PARKER, HY-LOK , DK-LOK , STAUFF, HYDAC , VOSS |
| MATERIAL DESIGNATOR | BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771. |
At Sumakhsteel, we take great pride in being the largest supplier and manufacturer in the USA, delivering advanced solutions for all your piping requirements. With cutting-edge production facilities strategically situated in the USA, we maintain an extensive inventory of more than 25,000 tons of premium-quality materials kept readily in stock.
Reach out to us for a fast quote tailored to your requirement.
We supply these Stainless Steel JIC Fittings conforming to DIN, ISO, JIS or ANSI Standard.
Stainless Steel JIC Fittings applications are as varied as the industries they serve, driven mainly by the aerospace, railway, construction and automotive industries along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, stainless steel JIC fittings can be recycled. Stainless steel is a material with high recyclability, and recycling these fittings helps preserve resources and cut down on waste. Through proper recycling of stainless steel JIC fittings, valuable materials can be recovered and put back into new manufacturing processes, supporting environmental sustainability and encouraging efficient resource management.
