Stainless Steel 321H Forging is renowned for its outstanding ability to withstand high temperatures and corrosion. Offering excellent mechanical properties, SS 321H forged components play a key role in aerospace, chemical and thermal environments. The elevated carbon content gives it greater durability and makes it well suited for applications demanding extended use at high temperatures. Discover precisely engineered stainless steel 321H forging solutions that satisfy stringent industry requirements while ensuring reliability and durability in harsh conditions.
| Chemical Composition, % | |||||||||||
| ASTM Type | AISI Type (UNS) | C, ≤ | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni | N, ≤ | Other Elements | Notes |
| ASTM A240/A240M | 321 (UNS S32100) | 0.08 | 0.75 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.10 | ≥ Ti 5×(C+N), ≤ 0.70 | Plate, Sheet, and Strip for Pressure Vessels |
| ASTM A276A/276M | 1.00 | – | Stainless Steel Bars and Shapes | ||||||||
| ASTM A580/A580M | – | ≥ Ti 5×C | Stainless Steel Wire | ||||||||
| ASTM A959 | 0.10 | ≥ Ti 5×(C+N), ≤ 0.70 | Wrought Stainless Steels | ||||||||
| ASTM A473 | – | ≥ Ti 5×C | Stainless Steel Forgings | ||||||||
| ASTM A314 | – | ≥ Ti 5×(C+N), ≤ 0.70 | Billets and bars for forging | ||||||||
| ASTM A240/A240M | 321H (UNS S32109) | 0.04-0.10 | 0.75 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.10 | ≥ Ti 4x(C+N), ≤ 0.70 | Plate, Sheet, and Strip |
| ASTM A959 | 1.00 | 0.10 | Wrought Stainless Steels | ||||||||
| ASTM A312/A312M | TP321 (UNS S32100) | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.10 | ≥ Ti 5×(C+N), ≤ 0.70 | Stainless Steel Pipes |
| TP321H (UNS S32109) | 0.04-0.10 | 1.00 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.10 | ≥ Ti 4x(C+N), ≤ 0.70 | ||
| SS 321 Mechanical Properties | |||||||||
| ASTM | AISI Type (UNS) | Conditions | Tensile Strength, MPa (ksi), ≥ | 0.2% Yield Strength, MPa (ksi), ≥ | Elongation in 50 mm (2 in.), %, ≥ | Reduction of Area, %, ≥ | Brinell Hardness (HBW), ≤ | Rockwell Hardness (HRBW), ≤ | Product forms |
| ASTM A276/A276M | 321 (UNS S32100) | Annealed, Hot finished | 515 (75) | 205 (30) | 40 | 50 | – | – | Bars and Shapes |
| Annealed, Cold finished, Dia ≤ 12.7 mm (0.5 in.) | 620 (90) | 310 (45) | 30 | 40 | – | – | |||
| Annealed, Cold finished, Dia > 12.7 mm (0.5 in.) | 515 (75) | 205 (30) | 30 | 40 | – | – | |||
| ASTM A580/A580M | Annealed | 520 (75) | 210 (30) | 35 | 50 | Wire | |||
| Cold finished | 620 (90) | 310 (45) | 30 | 40 | – | – | |||
| ASTM A473/A473M | Annealed, Sections ≤ 5 in. (127 mm) | 515 (75) | 205 (30) | 40 | 50 | – | – | Forgings | |
| Annealed, Sections > 5 in. (127 mm) | 70 (485) | ||||||||
| ASTM A240/A240M | 321, 321H (UNS S32109) | – | 515 (75) | 205 (30) | 40 | – | 201 | 92 | Plate, Sheet, and Strip |
At Sumakhsteel, we pride ourselves on being the largest supplier and manufacturer in the USA, delivering advanced solutions for every piping requirement you have. Backed by modern production facilities strategically placed across the USA, we maintain an extensive stock of more than 25,000 tons of top-grade materials kept ready in inventory.
Reach out to us for a fast quote tailored to your requirement.
We supply These Stainless Steel 321H Forging conforming to DIN, ISO, JIS or ANSI Standard.
Stainless Steel 321H Forging uses are as varied as the sectors they support, led chiefly by the aerospace, railway, construction and automotive industries along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes Stainless Steel 321H forging can be recycled. As with other stainless steels, SS 321H is able to be recycled by melting and reprocessing without sacrificing its valuable properties. This recyclability promotes sustainable practices by preserving resources and lowering environmental impact. Recycled stainless steel 321H can be used to make new forgings and other products, making it an environmentally friendly option for a range of industrial applications centered on environmental stewardship.
