Inconel 617 Forgings are recognized for outstanding strength, resistance to oxidation and long-lasting durability in high-temperature settings. Composed mainly of nickel, chromium, cobalt and molybdenum, this high-performance alloy performs exceptionally in demanding applications such as gas turbines, petrochemical processing, and power generation. Inconel 617 delivers long-term reliability and performance, and it is the choice of preference for applications that demand consistent performance under extreme conditions.
| Specifications | ASTM B564, ASME SB564, AMS 5887 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Sumakhsteel, we’re proud to be the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. With cutting-edge manufacturing facilities strategically situated in the USA, we maintain an extensive stock of more than 25,000 tons of top-grade materials kept ready in inventory.
Reach out to us for a fast quote tailored to your requirement.
We provide these Inconel 617 Forging conforming to DIN, ISO, JIS or ANSI Standard.
Inconel 617 Forging uses are as varied as the sectors they cater to, led mainly by the aerospace, railway, construction and automotive industries along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes Inconel 617 forgings can also be recycled. Made up of valuable metals like nickel, chromium, cobalt, and molybdenum, these alloys are able to be effectively recovered and repurposed across a range of industrial uses. Recycling Inconel 617 aids in conserving resources, cutting down on waste, and lessening environmental impact, promoting sustainable manufacturing methods and effective resource management.
