Home > Stainless Steel > Stainless Steel 410 Pipe
Stainless Steel 410 Pipe is a variety of stainless steel piping manufactured from grade 410 stainless steel alloy. Recognized for its superior strength, longevity, and resistance to corrosion, stainless steel 410 is a martensitic stainless steel widely applied across numerous industrial uses. Stainless steel 410 pipes are well-suited for applications that demand moderate corrosion resistance along with solid mechanical properties, including the production of automotive components, oil and gas equipment, and industrial machinery. These pipes deliver outstanding hardness and wear resistance, which makes them appropriate for use in high-stress settings.
| Dimensions | : | ASTM, ASME and API |
|---|---|---|
| Standard | : | ASTM A312 / ASTM SA312 |
| Size | : | 1/8” NB to 36” NB, 1/4” OD to 36” OD |
| Specialized in | : | Large Diameter Size |
| Outer Diameter | : | 6.35 mm O.D to 114.3 mm O.D |
| Thickness | : | 0.8 mm to 12.7 mm |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Type | : | Welded |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End |
| Grade | Ni | Mn | P | C | S | Si | Cr | Mo | N | |
| 410 | min. | – | – | – | – | – | – | 11.5 | – | – |
| max. | 0.75 | 1.00 | 0.040 | 0.15 | 0.030 | 1.00 | 13.5 | |||
| Tempering Temperature (0C) | Tensile Strength (MPa) | Impact Charpy V (J) | Elongation (% in 50mm) | Yield Strength 0.2% Proof (MPa) | Hardness Brinell (HB) |
| Annealed * | 480 min | – | 16 min | 275 min | – |
| 204 | 1310 | 30 | 16 | 1000 | 388 |
| 316 | 1240 | 36 | 14 | 960 | 325 |
| 427 | 1405 | # | 16 | 950 | 401 |
| 538 | 985 | # | 16 | 730 | 321 |
| 593 | 870 | 39 | 20 | 675 | 255 |
| 650 | 755 | 80 | 23 | 575 | 225 |
At Sumakhsteel, we’re proud to be the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. Featuring cutting-edge manufacturing facilities strategically situated across the USA, we maintain an extensive stock of more than 25,000 tons of top-grade materials on hand and ready to ship.
Reach out to us for a fast quote tailored to your needs.
We supply These Stainless Steel 410 Pipe in accordance with DIN, ISO, JIS or ANSI Standard.
Stainless Steel 410 Pipes find uses that vary as widely as the industries relying on them, led chiefly by the aerospace, railway, construction and automotive industries along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes Stainless Steel 410 Pipes can be joined through standard welding methods including TIG (Tungsten Inert Gas) welding, MIG (Metal Inert Gas) welding, or shielded metal arc welding (SMAW). That said, it’s crucial to apply correct welding procedures and methods to avoid overheating and warping of the material. Furthermore, preheating and post-welding annealing might be required to reduce the chance of cracking and guarantee the best possible weld quality.
Yes, stainless steel 410 pipes can be joined by welding using standard methods like TIG (Tungsten Inert Gas) welding, MIG (Metal Inert Gas) welding, or shielded metal arc welding (SMAW). Nevertheless, it’s crucial to follow correct welding procedures and techniques to avoid overheating and warping of the material. Furthermore, preheating and post-welding annealing might be required to reduce the chance of cracking and to guarantee the best possible weld quality.
Stainless steel 410 pipes are typically not advised for potable water use because their corrosion resistance is lower than that of other stainless steel grades like 304 or 316. Although grade 410 provides good strength and durability, it is more susceptible to corrosion in settings that contain chloride ions, which are frequently present in water. For potable water use, safeguarding the safety and health of consumers is critical, so it is recommended to select stainless steel grades made specifically for these purposes, such as 304 or 316, which deliver superior corrosion resistance and are approved for drinking water systems by regulatory bodies.
Yes, 410 stainless steel pipes are weldable through standard welding methods including TIG (Tungsten Inert Gas) welding, MIG (Metal Inert Gas) welding, or shielded metal arc welding (SMAW). That said, applying correct welding procedures and techniques is critical to avoid overheating and warping of the material. Furthermore, preheating and post-weld annealing might be required to reduce the chance of cracking and guarantee the best possible weld quality.
