Home > Stainless Steel > Stainless Steel Coils
Stainless Steel Coils are akin to the unsung champions of many industries, quietly safeguarding the integrity and lasting performance of countless products. custom-made from a mixture of iron, chromium, and nickel, these coils offer exceptional durability and resistance to corrosion. From the shining surfaces of kitchen appliances to the sturdy structures of automotive components, stainless steel coils contribute their strength and dependability to a wide range of uses. Their adaptability, along with different grades designed for particular requirements, makes them essential in both industrial and consumer spheres. Whether it’s the polished finish of a luxury car or the sanitary surfaces of medical equipment, stainless steel coils serve as proof of the union of form and function in modern manufacturing.
| Item | SS Coil(Hot rolled, cold rolled) |
| Inner Diameter | 610 +0/-5 mm |
| Width | 610~2000 mm |
| Thickness | 2.5~10.0 mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Material | SS 202 Coils, SS 304 Coils, SS 316 Coils, SS 321 Coils, SS 310 Coils , SS 410 Coils, SS 420 Coils, SS 416 Coils |
| Surface | 2D, etching, 8K, 2B, BA, NO.4, hair line,NO.1, NO.8, Brush, checkered, mirror,embossed, sand blast etc |
| Standard | ASTM A240, ASTM A167, JIS4304-2005, GB/T3280-2007, EN10088-2-2005, etc |
| origin | Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin |
| Density | Melting Point | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | ||
Rockwell B (HR B) max | Brinell (HB) max | |||||||
Stainless Steel Coil | 8.0 g/cm3 | 1400 °C (2550 °F) | 515 | 205 | 35 – 40 | 92 | 304 | |
|
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|||
|
Stainless Steel Coil |
min. max. |
– 0.08 |
– 2.0 |
– 0.75 |
– 0.045 |
– 0.030 |
18.0 20.0 |
– |
8.0 11 |
– – |
|
At Sumakhsteel, we take pride in being the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. With cutting-edge production facilities strategically situated across the USA, we maintain an extensive inventory of more than 25,000 tons of top-quality materials kept ready in stock.
Reach out to us for a fast quote tailored to your needs.
Estos serpentines de acero inoxidable se ofrecen conforme a la norma DIN, ISO, JIS o ANSI.
Stainless Steel Coils applications are as varied as the industries they cater to, driven mainly by the aerospace, railway, construction and automotive industries along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, stainless steel coils can be recycled to a high degree. Stainless steel is a valuable material that keeps its properties across multiple recycling cycles without any loss of quality. Recycling stainless steel coils helps preserve natural resources, lower energy use, and reduce environmental impact when compared to making new stainless steel from raw materials. The recycling procedure consists of melting the coils and reusing the material in a range of applications, which makes it a sustainable and eco-friendly option.
Yes, stainless steel coils are typically compatible with other piping materials. Stainless steel offers outstanding corrosion resistance and mechanical properties, which makes it appropriate for use together with a range of materials like carbon steel, copper, brass, and plastics in piping systems. That said, compatibility factors should still be evaluated based on considerations such as the specific grades of stainless steel and other materials, operating conditions (e.g., temperature, pressure, and fluid composition), and the possibility of galvanic corrosion. Proper insulation, gaskets, and joint connections can help reduce any compatibility problems and ensure the durability and performance of the piping system.
Yes Stainless steel coils are suitable for use in potable water systems. Because stainless steel has strong resistance to corrosion, it works well when in contact with drinking water. It won’t release harmful substances into the water and keeps its integrity even under demanding water conditions. That said, choosing the correct grade of stainless steel for potable water use is essential to meet regulatory standards and avoid any possible contamination. Consistent upkeep and correct installation methods matter too, helping preserve water quality and extend the lifespan of the system.
