| Standard | ASTM B 622, B 619 / ASME SB 622, SB 619 |
| Standard | ASTM, ASME and API |
| Size | 15 NB UP TO C22 NB IN SCH 5S, 10S,10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160 & XXS |
| Length | Single Random, Double Random & Required Length, Cut Length |
| End | Plain End, Beveled End, Treaded |
| Grade | C | Mn | Si | Co | P | Fe | Mo | Ni | Cr | S | W | V |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hastelloy C22 | 0.010 max | 0.50 max | 0.08 max | 2.5 max | 0.02 max | 2 – 6 | 12.5 – 14.5 | Bal | 20 – 22.5 | 0.02 max | 2.5 – 3.5 | 0.35 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45% |
At Sumakhsteel, we take great pride in being the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. With cutting-edge manufacturing facilities strategically situated across the USA, we maintain an extensive stock of more than 25,000 tons of top-quality materials always on hand and ready to ship.
Reach out to us for a fast quote tailored to your needs.
We supply these Hastelloy C22 Pipes conforming to DIN, ISO, JIS or ANSI Standard.
Corrosion Resistance: Hastelloy C22 pipes deliver outstanding corrosion resistance across a wide range of environments, including aggressive acids such as sulfuric acid, hydrochloric acid, phosphoric acid, and acetic acid. This corrosion resistance applies to both oxidizing and reducing conditions.
Versatility: These pipes are suited for a variety of applications across industries, including chemical processing, pharmaceuticals, pollution control, pulp and paper manufacturing, waste treatment, and more. Their versatility makes them highly desirable for applications demanding critical corrosion resistance.
High-Temperature Resistance: Hastelloy C22 pipes can endure high temperatures and thermal stress without significant degradation. This makes them well suited for applications involving high-temperature processes or environments.
Mechanical Strength: Hastelloy C22 pipes have excellent mechanical strength, enabling them to hold up under stress and pressure during operation. This mechanical robustness ensures the reliability and durability of the piping system.
Fabricability: These pipes are remarkably easy to fabricate, weld, and form into various shapes, which streamlines the manufacturing process and permits customization to match precise project requirements.
Low maintenance: Hastelloy C22 pipes need little maintenance thanks to their outstanding corrosion resistance. This lowers downtime and expenses for industrial facilities.
Longevity: Hastelloy C22 pipe has a long service life, even in demanding environments, which translates into less frequent replacement and lower overall costs
Safety: The corrosion resistance and mechanical properties of Hastelloy C22 pipe enhance the safety of industrial products by lowering the risk of leakage, failure and environmental impact
Chemical: Hastelloy C22 pipes see extensive use in the chemical sector for managing aggressive chemicals like sulfuric acid, hydrochloric acid, phosphoric acid, acetic acid, chlorine gas, and more. They work well in chemical plants, distillation columns, and piping systems where resistance to corrosion is essential.
Oil and Gas: Within the oil and gas sector, Hastelloy C-22 pipelines serve surface, midstream, and downstream applications that face environmental corrosion. They carry water and air pollutants to offshore platforms, oil refineries, pipelines, and petrochemical plants
Pulp & Paper: Hastelloy C22 pipe is applied in the pulp and paper sector for managing bleaching agents, chlorinated water, and other corrosive chemicals involved in papermaking. It serves in pulp digesters, bleaching plants, and chemical recovery systems.
Pharmaceuticals: Hastelloy C22 pipe serves the pharmaceutical sector in producing pharmaceutical intermediates and active pharmaceutical ingredients (APIs). It is well suited to managing volatile solvents, acids, and other pharmaceutical uses.
Waste Treatment: Hastelloy C22 pipe serves in waste treatment facilities for managing decomposing waste that contains strong chemicals such as acids, bases, and similar substances. It finds use across industries, for example in wastewater treatment, detergent, and industrial wastewater systems.
Power Generation: Within power plants, Hastelloy C22 pipe serves in critical applications like heat exchangers, condensers, and boiler systems that demand corrosion resistance, particularly in high-temperature zones where heat and corrosion
Hastelloy C22 Pipes serve a wide range of uses across many industries, led chiefly by the aerospace, railway, construction and automotive sectors, along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Corrosion Resistance: Hastelloy C22 is recognized for its outstanding resistance to corrosion across a wide range of conditions, including both reduction and oxidation. Make sure the pipe you select offers the corrosion resistance your application demands.
Temperature and Pressure: Shows the temperature and pressure levels of the pipes used in your application. Hastelloy C22 pipe offers excellent strength at high temperatures and can endure high-pressure settings, but it is important to align these characteristics with your requirements.
Size and Design: Think about the required size and thickness of the pipe for your project. Confirm that the pipe size, wall thickness, and length fulfill your order.
End connections: Indicate the kind of end connections your application calls for, such as welded, threaded, or flanged. Pick a pipe with the appropriate end connections to guarantee it works with your design.
Quality and Certification: Select pipe from a trusted manufacturer that satisfies quality standards and certifications. To confirm quality and reliability, seek out a pipe that complies with industry standards like ASTM, ASME, and ANSI.
Chemical compatibility: Take into account the chemical makeup of Hastelloy C22 and the materials it will involve in your application. Verify that the pipe is appropriate for handling the specific chemicals in your application.
Cost and Finance: Review the price of Hastelloy C22 pipes to determine whether they fit within your budget limits. Although Hastelloy C22 is valued for its performance, striking a balance between performance and cost is important.
Supplier Reputation: Pick a dependable supplier with a demonstrated history of delivering high-quality Hastelloy C22 pipe. Look into the reputation of suppliers, customer reviews, and prior performance, and make certain you obtain a pipe from a trustworthy source.
| Nominal Pipe Size (NPS) | Outside Diameter (OD) | Schedule |
|---|---|---|
| 1/8″ | 0.405″ | 10, 40, 80 |
| 1/4″ | 0.540″ | 10, 40, 80 |
| 3/8″ | 0.675″ | 10, 40, 80 |
| 1/2″ | 0.840″ | 10, 40, 80 |
| 3/4″ | 1.050″ | 10, 40, 80 |
| 1″ | 1.315″ | 10, 40, 80 |
| 1 1/4″ | 1.660″ | 10, 40, 80 |
| 1 1/2″ | 1.900″ | 10, 40, 80 |
| 2″ | 2.375″ | 10, 40, 80 |
| 2 1/2″ | 2.875″ | 10, 40, 80 |
| 3″ | 3.500″ | 10, 40, 80 |
| 4″ | 4.500″ | 10, 40, 80 |
| 5″ | 5.563″ | 10, 40 |
| 6″ | 6.625″ | 10, 40 |
| 8″ | 8.625″ | 10, 40 |
| 10″ | 10.750″ | 10, 40 |
| 12″ | 12.750″ | 10, 40 |
