Home > Stainless Steel > Stainless Steel 310H Forged Fittings
| Standard | ASTM A182 / ASME SA182 |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 310H | 0.04 – 0.10 | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 – 26.00 | – | 19.00 – 21.00 | 53.885 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
At Sumakhsteel, we are proud to be the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. With modern manufacturing facilities strategically positioned across the USA, we maintain an extensive stock of more than 25,000 tons of top-grade materials kept ready in inventory.
Reach out to us for a fast quote tailored to your requirement.
We provide Stainless Steel 310H Forged Fittings conforming to DIN, ISO, JIS or ANSI Standard.
Owing to their outstanding characteristics, Stainless Steel 310H Forged Fittings serve as vital parts throughout numerous industrial fields. Celebrated for their ability to resist corrosion, they are broadly used in marine settings, withstanding the harsh demands of saltwater contact with durability and dependability. Within the construction sector, stainless steel fasteners hold a key position in structural assemblies, delivering firm connections while preserving structural integrity in outdoor and exposed conditions.
High-Temperature Applications: Stainless steel-310H lattice fittings are built to endure elevated temperatures, which makes them well-suited for uses in fields such as petrochemical, chemical processing and ambient heat treatment at high temperature at
Corrosion resistance: These materials deliver outstanding resistance to corrosion, particularly in settings containing acids, alkalis, and other corrosive substances, which is why they are applied in situations demanding corrosion resistance, such as marine oil, gas and chemicals.
Pressure applications: Stainless steel 310H forged fittings are able to handle high pressures, which makes them appropriate for use in piping systems running under high pressures, such as steam lines, hydraulic systems and industrial piping
Heat Exchangers: Stainless steel 310H mesh fittings are frequently employed in heat exchangers produced for a range of industrial applications owing to their strong thermal resistance and corrosion resistance
Power Generation: These materials prove useful in power plants, including power plants and nuclear reactors, where they serve in pipeline systems, valves, and other components that require resistance to rising temperatures and corrosion
Features: Stainless steel 310H is a grade designed for elevated temperatures, featuring an increased carbon content that gives it enhanced thermal characteristics. Verify that fittings are manufactured from this grade so they remain suitable for high-temperature uses.
Pressure Rating: Indicates how much pressure your application demands. Stainless steel 310H mesh fittings come in a range of pressure ratings, so select fittings capable of handling the highest pressure anticipated in your system.
Size and number: Think about the dimensions and quantity of fittings your piping system needs. Stainless steel 310H mesh fittings are offered in numerous sizes and configurations, such as elbow, tee, coupling, union and cross. Make sure the fittings match the pipe size and satisfy the dimensional needs of your system.
Temperature Range: Review your application’s temperature to confirm that stainless steel 310H lattice fittings can endure operating temperatures without sacrificing their mechanical properties or resistance to corrosion.
