| Standard | ASTM B166, B446, B425/ASME SB166, SB446, SB425 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Round bar Size | Diameter: 3-~800mm |
| Hex Bar Size | 2-100mm A/F |
| Square Bar Size | 4 to 100mm |
| Angle Bar Size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 135,000 , MPa – 930 | Psi – 70,000 , MPa – 482 | 45 % |
| Inconel 600 | 72.0 min | 14.0 – 17.0 | 6.0 – 10.0 | 0.15 max | 1.0 max | 0.015 max | 0.5 max | 0.5 max | 0.5 max |
| Grade | Ni | Cr | Cu | C | Mn | S | Mo | Si | Co |
| Inconel 718 | 50 – 55 | 17 – 21 | 0.3 max | 0.08 max | 0.35 max | 0.015 max | 2.8 – 3.3 | 0.35 max | 1.0 max |
At Sumakhsteel, we are proud to be the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. With cutting-edge manufacturing facilities strategically positioned across the USA, we maintain an extensive stock of more than 25,000 tons of top-grade materials kept ready in inventory.
Get in touch with us to receive a fast quote for your requirement.
We supply These Inconel Bars in accordance with DIN, ISO, JIS or ANSI Standard.
Inconel Bars have applications as varied as the industries they cater to, led mainly by the aerospace, railway, construction and automotive industries along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
1. Aerospace products: Inconel bars serve aerospace applications in construction materials, engine components, and exhaust systems because of their strong resistance to elevated temperatures and corrosion
2.Gas Turbines: Employed in gas turbine engines for turbine blades, combustion chambers, and additional high-temperature parts, where resistance to thermal cycling and oxidation is necessary
3.Chemical Properties: Inconel tape is applied in chemical plants for reactors, piping, and heat exchangers, where it withstands corrosion caused by acids, bases, and other aggressive chemicals
4.Oil and Gas Extraction: Inconel pads are utilized in oil and gas extraction equipment, including downhole equipment, valves, and tubing, where they endure hot weather and high temperatures
5.Power Generation: Employed in power plants for steam turbine components, boiler tubes, and heat exchangers, where high temperatures and corrosive conditions are endured
6.MARINE APPLICATIONS: Inconel bars are used in marine settings for propeller shafts, marine pipelines, and marine exhaust systems, where they withstand salt water and marine weather as it rots
7.Medical Devices: Inconel patches are employed in medical devices and implants, including surgical devices and implants, thanks to their biocompatibility, impermeability, and sterilization processes
8.Electrical Components: Applied in electrical components, including connectors, springs, and sensor housings, where non-magnetic materials and corrosion resistance are needed
1. Material grade choice: Inconel pads come in a range of grades, each intended for a particular use. Weigh factors like heat resistance, corrosion resistance, mechanical properties, and construction to select the grade that offers the best material combination for your application.
2.Heat Resistance: Take into account the highest temperature your application will reach and pick an Inconel grade with sufficient heat resistance so it remains stable and mechanically strong at elevated temperatures.
3.Corrosion resistance: Tiles ought to be evaluated for their resistance to corrosion from acids, alkalis, seawater, or aggressive chemicals. Pick an Inconel grade with sufficient corrosion resistance to guarantee durability and reliability.
4.Mechanical properties: Identify the mechanical demands of your application, such as tensile strength, yield strength, durability, and fatigue resistance. Choose an Inconel grade whose mechanical properties align with your application needs for verifying structural integrity and performance under load.
5.Manufacturing Assembly: Take manufacturing processes like machining, welding, forging, and heat treatment into account. Pick an Inconel grade that meets the necessary manufacturing processes to ensure ease of production and quality output.
6.Size and Dimensional Tolerances: Define the needed size, shape, and dimensional tolerances of the strips according to your application specifications and manufacturing requirements.
Yes, stainless Inconel bars are weldable. That said, their distinctive characteristics—like strong resistance to corrosion and durability at high temperatures—call for special attention. It is critical to properly prepare the surface, choose appropriate welding methods (e.g., TIG, MIG), pick the right filler materials (e.g., Inconel 625), and manage heat input carefully. Heat treatment after welding might also be required to reduce residual stresses. Following these guidelines leads to sound welds that preserve the integrity and performance of stainless Inconel bars across a range of uses.
TIG (Tungsten Inert Gas) welding is frequently advised for joining Inconel bars because of its accuracy, control, and capacity to create high-quality welds. Methods like Pulsed TIG welding and Gas Tungsten Arc Welding (GTAW) are likewise appropriate. It’s essential to use suitable filler materials made for Inconel, such as Inconel 625 or Inconel 718, and keep heat input controlled to reduce the chance of cracking.
