Inconel Flanges are essential parts recognized for their outstanding performance under extreme conditions. Made from the superalloy Inconel, they offer unmatched resistance to high temperatures, oxidation, and corrosion. This renders them essential in aerospace, chemical processing, and oil and gas industries, where ordinary materials fail to hold up. Celebrated for their durability and reliability, Inconel flanges are key to maintaining the integrity and longevity of piping systems, protecting critical operations even in the toughest environments.
| Specifications | ASTM B564 / ASME SB564 |
| Size | 1/2″NB TO 48″NB |
| Standards | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Grade | C | Mn | Si | Cr | S | Ni | Fe |
| 600 | 0.15 | 1.00 | 0.50 | 14.00 – 17.00 | 0.015 | 72.00 | 6.00 – 10.0 |
| 625 | 0.10 | 0.50 | 0.50 | – | 0.015 | 58.0 | 5.0 min |
| Grade | Inconel 600 |
|---|---|
| Density | 8.47 g/cm3 |
| Melting Point | 1413 °C (2580 °F) |
| Tensile Strength | Psi – 95,000 , MPa – 655 |
| Yield Strength (0.2%Offset) | Psi – 45,000 , MPa – 310 |
| Elongation | 40 % |
At Sumakhsteel, we’re proud to be the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. With cutting-edge manufacturing facilities strategically situated across the USA, we maintain an extensive stock of more than 25,000 tons of top-grade materials available on hand.
Reach out to us for a fast quote tailored to your needs.
Nós fornecemos essas Flanges Inconel de acordo com as normas DIN, ISO, JIS ou ANSI.
Inconel Flanges are widely employed across industries that demand outstanding performance in extreme conditions. Their remarkable resistance to elevated temperatures, corrosion, and mechanical stress renders them essential in aerospace, chemical processing, oil and gas, and power generation applications. From piping systems to pressure vessels, Inconel flanges deliver dependable operation in severe environments where conventional materials come up short. Their superior durability and toughness are vital to preserving operational integrity and safety across a wide range of industrial settings.
Aerospace: Inconel flanges serve in aircraft engines, gas turbines, and aerospace structures, settings where elevated temperatures, corrosion, and mechanical stresses commonly occur.
Chemical Processing: They are put to use in chemical processing plants for reactors, heat exchangers, and piping systems that manage corrosive chemicals and high temperatures.
Oil and Gas: Inconel flanges are applied in oil refineries, offshore platforms, and petrochemical facilities for pipelines, valves, and equipment subjected to corrosive environments and high temperatures.
Power Generation: They serve in power plants for boilers, steam turbines, and exhaust systems, where they endure high temperatures, pressure, and corrosive gases.
Marine Engineering: Inconel flanges are deployed in marine applications for seawater piping systems, offshore platforms, and marine propulsion systems owing to their corrosion resistance and durability.
Pulp and Paper: They are applied in pulp and paper mills for digesters, bleach towers, and recovery boilers, where they withstand corrosion from chemicals and high temperatures.
Automotive: Inconel flanges are used in automotive exhaust systems, turbochargers, and high-performance engines thanks to their heat resistance and capacity to endure harsh operating conditions.
Pharmaceuticals: They are utilized in pharmaceutical manufacturing for equipment like reactors, vessels, and piping systems, where cleanliness and corrosion resistance are essential.
Mining and Metallurgy: Inconel flanges are applied in mining operations and metallurgical plants for equipment subjected to high temperatures, corrosive environments, and abrasive materials.
Food and Beverage: Inconel flanges are used in food processing facilities for heat exchangers, storage tanks, and processing equipment, where they satisfy sanitary standards and resist corrosion from food acids.
Yes, Inconel Flanges can be welded using standard welding methods. When choosing Inconel flanges, verify that they are compatible with your welding processes and procedures.
Inconel Flanges typically adhere to industry standards like ASME, ASTM, ANSI, or DIN, guaranteeing quality, compatibility, and regulatory compliance.
Select trustworthy vendors that hold certifications, have industry expertise, and earn favorable customer feedback to guarantee product quality, uniformity, and on-time shipping.
Inconel Flanges are usually suited to common gasket materials like graphite, PTFE (Teflon), and spiral wound gaskets. That said, confirming compatibility with the particular gasket material and operating conditions is critical to guarantee proper sealing and performance.
|
Pipe Normal Diam. |
O.D. Flange |
Thk. Of Flange Min |
Diam.
of
Hub |
Diameter of Raised Face |
Length Hub.Y |
Thread Length |
Diam.
of Bolt
Circle |
Diam.
of Bolt
Holes |
Number
of Bolts |
Diam. of
Bolts
(inch) |
KG |
LB |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
inch |
dn |
O |
C |
X |
G |
Y |
T |
BC |
BH |
BN |
BD |
||
|
1/2″ |
15 |
89.00 |
11.20 |
30.20 |
35.10 |
15.70 |
15.70 |
60.50 |
15.80 |
4 |
1/2″ |
0.4 |
0.9 |
|
3/4″ |
20 |
98.50 |
12.70 |
38.10 |
42.90 |
15.70 |
15.70 |
69.90 |
15.80 |
4 |
1/2″ |
0.7 |
1.5 |
|
1″ |
25 |
108.00 |
14.20 |
49.30 |
50.80 |
17.50 |
17.50 |
79.30 |
15.80 |
4 |
1/2″ |
0.8 |
1.8 |
|
1-1/4″ |
32 |
117.50 |
15.70 |
58.70 |
63.50 |
20.60 |
20.60 |
88.90 |
15.80 |
4 |
1/2″ |
1.2 |
2.6 |
|
1-1/2″ |
40 |
127.00 |
17.50 |
65.00 |
73.20 |
22.40 |
22.40 |
98.60 |
15.80 |
4 |
1/2″ |
1.5 |
3.3 |
|
2″ |
50 |
152.50 |
19.10 |
77.70 |
91.90 |
25.40 |
25.40 |
120.70 |
19.10 |
4 |
5/8″ |
2.3 |
5.1 |
|
2-1/2″ |
65 |
178.00 |
22.40 |
90.40 |
104.60 |
28.40 |
28.40 |
139.70 |
19.10 |
4 |
5/8″ |
3.7 |
8.1 |
|
3″ |
80 |
190.50 |
23.90 |
108.00 |
127.00 |
30.20 |
30.20 |
152.40 |
19.10 |
4 |
5/8″ |
4.1 |
9 |
|
3-1/2″ |
90 |
216.00 |
23.90 |
122.20 |
139.70 |
31.80 |
31.80 |
177.80 |
19.10 |
8 |
5/8″ |
5.1 |
11.2 |
|
4″ |
100 |
228.50 |
23.90 |
134.90 |
157.20 |
33.30 |
33.30 |
190.50 |
19.10 |
8 |
5/8″ |
5.9 |
13 |
|
5″ |
125 |
254.00 |
23.90 |
163.60 |
185.70 |
36.60 |
36.60 |
215.90 |
22.40 |
8 |
3/4″ |
7 |
15.4 |
|
6″ |
150 |
279.50 |
25.40 |
192.00 |
215.90 |
39.60 |
39.60 |
241.30 |
22.40 |
8 |
3/4″ |
8.4 |
18.5 |
|
8″ |
200 |
343.00 |
28.40 |
246.10 |
269.70 |
44.50 |
44.50 |
298.50 |
22.40 |
8 |
3/4″ |
13 |
28.6 |
|
10″ |
250 |
406.50 |
30.20 |
304.80 |
323.90 |
49.30 |
49.30 |
362.00 |
25.40 |
12 |
7/8″ |
18 |
39.5 |
|
12″ |
300 |
482.50 |
31.80 |
365.30 |
381.00 |
55.60 |
55.60 |
431.80 |
25.40 |
12 |
7/8″ |
29 |
64 |
|
14″ |
350 |
533.50 |
35.10 |
400.10 |
412.80 |
57.20 |
57.20 |
476.30 |
28.50 |
12 |
1″ |
39 |
86 |
|
16″ |
400 |
597.00 |
36.60 |
457.20 |
469.90 |
63.50 |
63.50 |
539.80 |
28.50 |
16 |
1″ |
47 |
103 |
|
18″ |
450 |
635.00 |
39.60 |
505.00 |
533.40 |
68.30 |
68.30 |
577.90 |
31.80 |
16 |
1 1/8″ |
57 |
126 |
|
20″ |
500 |
698.50 |
42.90 |
558.80 |
584.20 |
73.20 |
73.20 |
635.00 |
31.80 |
20 |
1 1/8″ |
76 |
167 |
|
24″ |
600 |
813.00 |
47.80 |
663.40 |
692.20 |
82.60 |
82.60 |
749.30 |
35.10 |
20 |
1 1/4″ |
97 |
214 |
