| Stainless Steel 316L Tube Specification | ||
|---|---|---|
| Stainless Steel 316L Tube Dimensions | ASTM, ASME, API | |
| SS 316L Tubes Sizes (Seamless) | 1/2″ NB – 8″ NB | |
| 316L SS Tube SIzes (ERW) | 1/2″ NB – 24″ NB | |
| SS 316L Tubes Sizes (EFW) | 6″ NB – 100″ NB | |
| Wall Thickness of Seamless SS Tube | Schedule 5S – Schedule XXS (heavier on request) | |
| TubeWell Specialized in | Large Diameter Size | |
| SS 316L Tubes End | Plain End, Beveled End, Treaded | |
| Stainless Steel 316L Tubes Length | Single Random, Double Random & Cut Length. | |
| SS 316L Tubes Other Materials Testing | NACE MR0175, h3 SERVICE, OXYGEN SERVICE, CRYO SERVICE, etc | |
| Processing | Cut-to-length, polishing,Polished Grit 120 – 600 | |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| SS 316 Tube | 0.035 | 2 | 1 | 0.045 | 0.03 | 18.0-20.0 | 2.0-3.0 | 8.0-13.0 | – | |
| SS 316L Tube | min. | – | – | – | – | – | 16.0 | 10.0 | – | |
| max. | 0.035 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | – | ||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 316L Tube | 485 | 170 | 40 | 95 | 217 |
| SS 316 Tube | 515 | 205 | 40 | 95 | 217 |
At Sumakhsteel, we’re proud to be the largest supplier and manufacturer in the USA, delivering advanced solutions for every piping requirement you have. With cutting-edge manufacturing facilities strategically positioned across the USA, we maintain an extensive stock of more than 25,000 tons of top-grade materials always available on hand.
Reach out to us for a fast quote tailored to your requirement.
Nós fornecemos estes tubos de aço inoxidável 316L conforme as normas DIN, ISO, JIS ou ANSI.
Stainless Steel 316L Tubing applications are as varied as the industries they serve, driven mainly by the aerospace, railway, construction and automotive industries along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
