Home > Tantalum > Tantalum R05200 Sheets
Tantalum R05200 sheets are valued highly for their outstanding resistance to corrosion and excellent surface texture, which makes them essential in challenging applications like aerospace, electronics, chemical processing, and more. These sheets offer superb quality and biocompatibility for industrial use, guaranteeing dependability and precision in severe conditions. Tantalum R05200 sheets are designed to satisfy rigorous industry standards, delivering longevity and performance across a range of critical uses.
| Thickness (mm) | Width (mm) | Length (mm) | |
| Foil | 0.03-0.07 | 30-200 | >50 |
| Sheet | 0.07-0.5 | 30- 700 | 30-2000 |
| Board | 0.5-10 | 50-1000 | 50-3000 |
| Purity | >=99.95％ or 99.99％ | ||
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.060 in. thick | 30 000 (207) | 20 000 (138) | 20 |
| ≥0.060 in. thick | 25 000 (172) | 15 000 (103) | 30 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 0.05 | Remainder |
Sumakhsteel proudly holds its position as the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. Thanks to our modern manufacturing facilities positioned in prime locations across the USA, we maintain an extensive stock of more than 25,000 tons of top-grade materials on hand and ready to ship.
Reach out to us for a fast quote tailored to your requirement.
We supply these Tantalum R05200 Sheets in accordance with DIN, ISO, JIS or ANSI Standard.
Tantalum R05200 Sheets serve applications as varied as the industries they support, led chiefly by the aerospace, railway, construction and automotive industries, along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Tantalum R05200 sheets come in a range of configurations designed to fit varied industrial requirements. Frequently used types include flat sheets, which offer versatility for fabrication and welding; coils, which deliver flexibility across manufacturing processes; and strips, which work well for accurate cutting and forming. These configurations guarantee that Tantalum R05200 sheets satisfy demanding specifications for corrosion resistance, high-temperature performance, and durability in critical applications.
