Discover our range of Quenched and tempered Carbon Steel sheets and plates built for dependability and long-lasting performance across a wide range of industrial uses. Crafted for accuracy and versatility, our products satisfy industry benchmarks for outstanding strength. We put customer satisfaction first through tailored solutions, competitive pricing, and fast delivery. Elevate your projects with our reliable products, supported by a dedication to excellence.
| Standard | ASTM A514 and A514M-13 |
| Delivery State | Quenched and Tempered |
| Thickness: | 3 mm to 300 mm |
| Width: | 3000 mm, 2500 mm, 2000 mm, |
| Length: | Up to 12000 mm long |
| Grade | Grade 80, 400 and 500, WELTEN 780E, 140 KSI ,130 KSI , A710, A514, RQT 701, TMCP 100 KSI, S690QL, S690QL1, S890QL1, S690Q, Weldox 700, S890QL, S960QL, S890Q |
| A514 Gr A | A514 Gr B | A514 Gr E | A514 Gr H | A514 Gr C | A514 Gr S | A514 Gr F | A514 Gr M | A514 Gr J | A514 Gr K | A514 Gr R | A514 Gr P | A514 Gr Q | A514 Gr T | |
| C | 0.015-0.021 | 0.012-0.021 | 0.012-0.020 | 0.012-0.021 | 0.010-0.020 | 0.011-0.021 | 0.010-0.020 | 0.012-0.021 | 0.012-0.021 | 0.010-0.020 | 0.015-0.020 | 0.012-0.021 | 0.014-0.021 | 0.008-0.014 |
| M | 0.080-1.010 | 0.070-1.000 | 0.040-0.070 | 0.095-1.030 | 1.010-1.050 | 1.010-1.050 | 0.060-1.000 | 0.045-0.070 | 0.045-0.070 | 1.010-1.050 | 0.085-1.015 | 0.045-0.070 | 0.095-1.030 | 1.020-1.050 |
| P | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 |
| S | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0010 |
| Si | 0.040-0.080 | 0.020-0.035 | 0.020-0.040 | 0.020-0.035 | 0.015-0.030 | 0.015-0.045 | 0.015-0.035 | 0.020-0.035 | 0.020-0.035 | 0.015 | 0.020-0.035 | 0.020-0.035 | 0.015-0.035 | 0.040-0.060 |
| Ni | – | – | – | 0.030-0.070 | – | – | 0.070-1.000 | 1.020-1.050 | – | – | 0.090-1.010 | 1.020-1.050 | 1.020-1.050 | – |
| Cr | 0.050-0.080 | 0.040-0.065 | 1.040-2.000 | 0.040-0.065 | – | – | 0.040-0.065 | – | – | – | 0.035-0.065 | 0.085-1.020 | 1.000-1.050 | – |
| Mo | 0.018-0.028 | 0.015-0.025 | 0.040-0.060 | 0.020-0.030 | 0.015-0.030 | 0.010-0.060 | 0.040-0.060 | 0.045-0.060 | 0.050-0.065 | 0.045-0.060 | 0.015-0.025 | 0.045-0.060 | 0.045-0.060 | 0.045-0.060 |
| V | – | 0.003-0.008 | – | 0.003-0.008 | – | 0.006 | 0.003-0.008 | – | – | – | 0.003-0.008 | – | 0.003-0.008 | 0.003-0.008 |
| Ti | – | 0.001-0.003 | 0.001-0.010 | – | – | – | – | – | – | – | – | – | – | – |
| Z | 0.005-0.015 | – | – | – | – | – | – | – | – | – | – | – | – | |
| Cu | – | – | 0.015-0.050 | – | – | – | 0.015-0.050 | – | – | – | – | – | – | – |
| B | 0.00025 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | – | 0.0001-0.0005 | – | 0.0001-0.0005 |
| Nb | – | – | – | – | – | 0.006 | – | – | – | – | – | – | – | – |
| Grade | A514 Mechanical Property | |||
| Tensile | Yield | Elongation | Thickness | |
| A514 | Mpa | Min Mpa | Min % | mm |
| 760-895 | 690 | 18 | 20 | |
| 760-895 | 690 | 18 | 20-65 | |
| 690-895 | 620 | 18 | 65-150 | |
At Sumakhsteel, we take great pride in being the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. Backed by cutting-edge manufacturing facilities purposefully situated across the USA, we maintain an extensive stockpile of more than 25,000 tons of top-grade materials kept ready in stock.
Reach out to us for a fast quote tailored to your requirement.
Weld offer these Quenched & Tempered Carbon Steel Sheet & Plate conforming to DIN, ISO, JIS or ANSI Standard.
Quenched & Tempered Carbon Steel Sheet & Plate uses are as varied as the industries they cater to, led mainly by the aerospace, railway, construction and automotive sectors along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
When choosing quenched and tempered carbon steel sheets and plates, take into account the mechanical properties you need, like strength and hardness, the particular requirements of your application, resistance to wear and impact, how readily the material can be fabricated and welded, and whether the thickness and dimensions you want are obtainable. On top of that, verify that the grade you pick satisfies the applicable industry standards and specifications for quality and performance.
