Home > Zeron 100 Bolts
Discover our range of Zeron 100 Bolts, built to satisfy the strength and flexibility demands of a wide range of industries. Our bolts are well-known for their quality and durable performance, complying with industry standards for demanding environments. Customer satisfaction comes first for us, which is why we provide customized solutions, competitive pricing, and on-time delivery. Elevate your business with our dependable products, supported by our dedication to excellence.
| UNS S32760 Fg Bolts, Studs Threads: | METRIC, BSW, BSF, UNC, UNF or as required |
|---|---|
| Zeron 100 Threaded Rod Standard: | ANSI – American National Standards Institute
|
| Zeron 100 Fasteners Material Specification | Zeron 100 Fasteners , UNS S32760 Bolts |
| S32760 Fasteners / Bolts Standard | DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM and all International Standards |
| 1.4501 UNS S32760 Fasteners/ Bolts Size | M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160 |
| Length of S32760 Hex Bolt | 3 mm to 200 mm |
| Source of raw materials to manufacture 1.4501 UNS S32760 Screw | Tata Steel, JSPL, RINL, Usha Martin, Dhamm Steel, Mukund Steel etc. |
| Zeron 100 Hex Bolt Thread | Metric Coarse |
| S32760 bolting Test Certificate: | Manufacturer Test Certificate as per EN 10204 / 3.1 |
| Zeron 100 Bolts finishing: | Zinc (yellow, white, blue, black), black oxide, Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Stainless steel: Passivated Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Mechanically Applied coating and some special one like DACROMET |
| Production process | M2-M24: Cold Froging, hot forging M24-M100, machining and CNC for Customized connecting element |
| SCOPE |
|
| Zeron 100 Nut In Form of: | Hex, Square, Round, Threading as per Gauge Etc. |
| Head drive: | Phillips, Slotted, Phillips/Slot, Six-Lobe, etc |
| DIN 1.4501 bolting materials Surface Coating: |
|
| Super Duplex UNS S32760 Bolts types | Zeron 100 Hex Bolts, Flange Bolts, Hex Head Bolts, Lag Bolts, Square Bolts, Eye Bolts, U Bolts, T Bolts, Counter sunk Bolts etc. |
| ASTM A479/a276 UNS S32760 Nut types | Zeron 100 Hex Head Nut, Eye Nut, Dome Nut, Wing Nut, T Nut, Panel Nut, Lock Nut, Coupling Nut, Square Nut, Acorn Nut etc. |
| Zeron 100 Screws types | Zeron 100 Hex Head Cap Screws, Socket Set Screws, Anchor Screws, Blind Rivet, Socket Head Screws, Concrete Screws, Shoulder Screws, Panel Screws, Threaded Screws, Machine Screws etc. |
| S32760 Washer types | Zeron 100 Machine Washers, Flat Washer, Star Washers, Sealing Washer, Lock Washer, Split Washer in India |
| Zeron 100x Fasteners Packing: | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Ready stock available metric Zeron 100 Bolts |
|
| % | Cr | Ni | Mo | Cu | W | C | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min | 24 | 6 | 3 | 0.5 | 0.5 | – | 0.2 | – | – | – | – | – |
| Max | 26 | 8 | 4 | 1 | 1 | 0.03 | 0.3 | 1 | 1 | 0.030 | 0.010 | Balance |
| Mechanical & Physical Properties | -70°C | -46°C | 21.1 °C | 93.3°C | 148.9 °C | 204.4 °C | 250 °C | 300°C |
|---|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength, MPa | – | – | 750 | 670 | 620 | 610 | 600 | 590 |
| 0.2% Yield Strength, MPa | – | – | 550 | 430 | 400 | 380 | 370 | 360 |
| Reduction of area % | – | – | – | – | – | – | – | – |
| Elongation % | – | – | 25 | – | – | – | – | – |
| Charpy Impact V-notch /J | >45 | >45 | 100 | – | – | – | – | – |
| Coefficient of Thermal Expansion /µm/m°C | – | – | – | 12.8 | – | 13.3 | – | 13.8 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | – | 11.094 | 12.384 | 13.244 | 14.018 | 14.878 | 15.652 |
| Modulus of Elasticity / GPa | – | – | 200 | 194 | – | 186 | – | 180 |
| NOMINAL SIZE (D) | BODY DIAMETER | HEAD THICKNESS | ACROSS THE FLATS | ACROSS CORNERS | ||||
|---|---|---|---|---|---|---|---|---|
| D (MAX) | D (MIN) | H (MAX) | H (MIN) | F (MAX) | F (MIN) | C (MAX) | C (MIN) | |
| m10 | 10.00 | 9.78 | 6.63 | 6.17 | 17.00 | 15.73 | 18.48 | 17.77 |
| m12 | 12.00 | 11.73 | 7.76 | 4.24 | 19.00 | 17.73 | 20.78 | 20.03 |
| m14 | 14.00 | 13.73 | 9.09 | 8.51 | 22.00 | 20.67 | 24.25 | 23.35 |
| m16 | 16.00 | 15.73 | 10.32 | 9.68 | 24.00 | 23.67 | 27.71 | 26.75 |
| m20 | 20.00 | 19.67 | 12.88 | 12.12 | 30.00 | 29.16 | 34.64 | 32.95 |
| m24 | 24.00 | 23.67 | 15.44 | 14.56 | 36.00 | 35.00 | 41.57 | 39.55 |
| m30 | 30.00 | 29.67 | 19.48 | 17.92 | 46.00 | 45.00 | 53.12 | 50.85 |
| m36 | 36.00 | 35.61 | 23.38 | 21.63 | 55.00 | 53.80 | 63.51 | 60.79 |
| m42 | 42.00 | 41.38 | 26.97 | 25.03 | 65.00 | 62.90 | 75.06 | 71.71 |
| m48 | 48.00 | 47.38 | 31.07 | 28.93 | 75.00 | 72.60 | 86.60 | 82.76 |
| m56 | 56.00 | 55.26 | 36.2 | 33.80 | 85.00 | 82.20 | 98.15 | 93.71 |
| m64 | 64.00 | 63.26 | 41.32 | 38.68 | 95.00 | 91.80 | 109.70 | 104.65 |
| m72 | 72.00 | 71.26 | 46.45 | 43.55 | 105.00 | 101.40 | 121.24 | 115.60 |
| m80 | 80.00 | 79.26 | 51.58 | 48.42 | 115.00 | 111.00 | 132.72 | 126.54 |
| m90 | 90.00 | 89.13 | 57.74 | 54.26 | 130.00 | 125.50 | 150.11 | 143.07 |
| m100 | 90.00 | 99.13 | 63.9 | 60.10 | 145.00 | 140.00 | 167.43 | 159.60 |
Sumakhsteel proudly stands as the largest supplier and manufacturer in the USA, delivering advanced solutions for every piping requirement you may have. Thanks to our modern manufacturing facilities positioned in key locations across the USA, we maintain an extensive stock of more than 25,000 tons of top-grade materials, all kept ready and available in inventory.
Reach out to us for a fast quote tailored to your requirement.
We supply these Zeron 100 Bolts in accordance with DIN, ISO, JIS or ANSI Standard.
Zeron 100 Bolts applications are as varied as the sectors they serve, led chiefly by the aerospace, railway, construction and automotive industries along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Choosing the correct Zeron 100 bolts requires weighing factors such as the operating environment (corrosive or high temperature), load demands, and particular application requirements. It is essential to evaluate compatibility with the materials being joined and to confirm accurate sizing and thread pitch. Seeking advice from a materials specialist or checking manufacturer specifications can help in making the right choice for peak performance and durability.
