Home > Inconel Manifold Valve
Inconel Manifold Valve are vital parts engineered for demanding industrial settings where corrosion and elevated temperatures are frequent. Constructed from rugged Inconel alloy, these valves withstand oxidation, chemicals and erosion. Several valves are combined into one unit to streamline the water management system, guaranteeing precise water management and distribution. Because of their toughness and dependability, Inconel manifold valves serve a key function in the effective and safe operation of critical industrial applications.
| MATERIAL | INCONEL |
| VALVES SIZE | 1/8″ – 1″ |
| THREAD | BSPP, NPT, BSPT |
| CONNECTION | FLANGE END, THREADED |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, ROSE MOUNT, HOKE |
| FUNCTION | 3 WAY, 2 WAY, 5 WAY |
| TYPE | T TYPE, R TYPE, H TYPE |
| BODY SHAPE | RECTANGLE, SQUARE |
| ORIFICE SIZE | 2 MM – 9.5 MM |
| PRESSURE RATING | 3000 PSI, 1500 PSI, 10000 PSI, 6000 PSI, 15,000 PSI |
| MEDIA TEMPERATURE | (-120* C – 500*C ) AS PER PRESSURE RANGE |
| HANDLE | BAR T-HANDLE |
| BODY TYPE | FORGED, BAR STOCK |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Inconel | Element (% By Mass) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nb | Cr | Mn | Ni | Fe | Mo | Co | Al | S | Si | Cu | C | B | Ti | P | |
| 617 | 20.0–24.0 | 0.5 | 44.2–56.0 | 3.0 | 8.0–10.0 | 10.0–15.0 | 0.8–1.5 | 0.015 | 0.5 | 0.5 | 0.15 | 0.006 | 0.6 | 0.015 | |
| X-750 | 0.7–1.2 | 14.0–17.0 | 1.0 | 70.0 | 5.0–9.0 | 1.0 | 0.4–1.0 | 0.01 | 0.5 | 0.5 | 0.08 | 2.25–2.75 | |||
| 600 | 14.0–17.0 | 1.0 | 72.0 | 6.0–10.0 | 0.015 | 0.5 | 0.5 | 0.15 | |||||||
| 690 | 30 | 0.35 | 59.5 | 9.2 | 0.02 | 0.003 | 0.35 | 0.01 | 0.019 | ||||||
| 625 | 3.15–4.15 | 20.0–23.0 | 0.5 | 58.0 | 5.0 | 8.0–10.0 | 1.0 | 0.4 | 0.015 | 0.5 | 0.1 | 0.4 | 0.015 | ||
| 718 | 4.75–5.5 | 17.0–21.0 | 0.35 | 50.0–55.0 | Balance | 2.8–3.3 | 1.0 | 0.65–1.15 | 0.015 | 0.35 | 0.2–0.8 | 0.08 | 0.006 | 0.3 | 0.015 |
| Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Brinell (HB) max | Rockwell B (HR B) max | |||
| Psi – 1,35,000 , MPa -930 | 42.5 | Psi – 75,000 , MPa – 517 | – | – |
At Sumakhsteel, we take pride in being the largest supplier and manufacturer in the USA, delivering advanced solutions for every one of your piping requirements. With cutting-edge manufacturing facilities strategically positioned across the USA, we maintain an extensive inventory of more than 25,000 tons of top-grade materials kept ready in stock.
Reach out to us for a fast quote tailored to your needs.
We supply these Inconel Manifold Valve conforming to DIN, ISO, JIS or ANSI Standard.
Inconel Manifold Valve uses span across a wide range of sectors, led mainly by the aerospace, railway, construction and automotive industries, along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
When installing Inconel manifold valves, several factors help guarantee peak performance and durability. Begin by confirming compatibility with the system’s fluid type, pressure, and temperature demands, since Inconel alloys are selected for their resistance to corrosion and their ability to handle high temperatures. Correct alignment and firm mounting are essential to avoid leaks and to guarantee dependable operation across changing conditions. Employ sealing materials that are compatible with and appropriate for Inconel alloys to preserve valve integrity. Adhere to the manufacturer’s instructions for installation steps to get the most efficiency and longest life out of the valve.
