Hastelloy Manifold Valves are vital parts engineered for dependable performance in high-temperature mechanical settings. Constructed from rugged Hastelloy alloy, these valves perform exceptionally well in acidic and chemical seawater conditions. Several valves are combined into one assembly to streamline the water management system, guaranteeing precise water control and distribution. Thanks to their outstanding corrosion resistance and strength, Hastelloy valves promote safety and efficiency in vital industrial applications.
| MATERIAL | HASTELLOY |
| VALVE SIZE | 1/8″ TO 1″ |
| THREAD | NPT, BSPP, BSPT |
| CONNECTION | THREADED, FLANGE END |
| TYPE | R TYPE, T TYPE, H TYPE |
| FUNCTION | 2 WAY, 3 WAY, 5 WAY |
| BODY SHAPE | SQUARE, RECTANGLE |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI |
| ORIFICE SIZE | 2 MM TO 9.5 MM |
| MEDIA TEMPERATURE | (-120* C TO 500*C ) RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK, FORGED |
| HANDLE | BAR T-HANDLE |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, ROSE MOUNT, HAMLET, OLIVER VALVES, HOKE |
| Hastelloy C276 | Co | Ni | C | Mn | Mo | Cr | Fe | S | Si | P |
| 2.5 Max | Balance | 0.010 Max | 1.00 Max | 15.00 – 17.00 | 14.50 – 16.50 | 4.00 – 7.00 | 0.03 Max | 0.08 Max | 0.04 Max | |
| Hastelloy C22 | 2.5 Max | Balance | 0.010 Max | 0.50 Max | 12.5 – 14.5 | 20 – 22. | 2 – 6 | 0.02 Max | 0.08 Max | 0.02 Max |
| Yield Strength (0.2%Offset) | Density | Melting Point | Tensile Strength | Elongation | |
|---|---|---|---|---|---|
| C22 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 8.69 G/Cm3 | 45 % |
| C276 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 8.89 G/Cm33 | 40% |
| B2 | 1370 °C (2550 °F) | Psi – 1,15,000 , MPa –760 | Psi – 52,000 , MPa – 350 | 9.2 G/Cm3 | 40% |
| B3 | 1370 °C (2550 °F) | Psi – 1,15,000 , MPa –760 | Psi – 52,000 , MPa – 350 | 9.2 G/Cm3 | 40% |
| C4 | 1350-1400 °C | 783 | 365 | 8.64 G/Cm3 | 55% |
| Hybrid BC1 | 1343 – 1443°C | 725 | 310 | 8.83 G/Cm³ | 40% |
| X | 1355°C | 655 MPa | 240 MPa | 8.22 G/Cm³ | 35% |
At Sumakhsteel, we take great pride in being the largest supplier and manufacturer in the USA, delivering advanced solutions for all your piping requirements. Featuring modern production facilities strategically situated in the USA, we maintain an extensive inventory of more than 25,000 tons of top-quality materials kept ready in stock.
Reach out to us for a fast quote tailored to your requirement.
We supply these Hastelloy Manifold Valve conforming to DIN, ISO, JIS or ANSI Standard.
Hastelloy Manifold Valve uses span across an array of sectors as broad as the industries they support, led chiefly by the aerospace, railway, construction and automotive fields, along with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
When installing Hastelloy manifold valves, a number of factors are essential for achieving the best performance and durability. To begin with, verify that the valve is suited to the system’s fluid type, pressure, and temperature demands, since Hastelloy alloys are selected for their resistance to corrosion and their ability to withstand high temperatures. Correct alignment and firm mounting are vital to avoid leaks and guarantee dependable operation across changing conditions. Employ sealing materials that are compatible with and appropriate for Hastelloy alloys to preserve the valve’s integrity. Adhere to the manufacturer’s instructions for installation to get the most out of the valve’s efficiency and service life.
